Efficiencies
| Total System Efficiency | 130 lm/W |
|---|---|
| The performance of each component of a luminaire is demonstrated through its efficiencies, which together determine the total system efficiency of the product. The output of the LED chip is first multiplied by the optical and thermal efficiencies to calculate the Luminaire efficiency. However, this calculation does not consider the driver efficiency. To determine the overall efficiency of the system, the Luminaire efficiency must be multiplied by the driver efficiency, which accounts for all losses in the system. | |
Mechanical
| IP Rating | IP65 |
|---|---|
| IK Rating | IK08 |
| Body Material | Polycarbonate |
| Diffuser Material | Polycarbonate |
| Installation Type | Surface mount |
Electrical
| Working Temp Range | 0 to 40 °C |
|---|---|
| Input Frequency | 50 Hz |
| Electrical Rating | Class I |
| System Max Wattage | |
| EV-QUADRO-ADV EV-QUADRO-ADV-S | 20 W |
| EV-QUADRO-EM-ADV EV-QUADRO-EM-ADV-S | 23 W |
| Input voltage | 230Vac |
| In Australia the Input voltage is defined as 230Vac -6%/+10%. This effectively means that the voltage range of these products are 216Vac - 253Vac or 240V +6% | |
| Switch Type | Mains-DALI |
| Power Factor | 0.95 |
| Maximum Wattage | |
| EV-QUADRO-PRO EV-QUADRO-PRO-LK EV-QUADRO-PRO-S EV-QUADRO-PRO-S-LK | 25 W |
| EV-QUADRO-EM-PRO EV-QUADRO-EM-PRO-LK EV-QUADRO-EM-PRO-S EV-QUADRO-EM-PRO-S-LK | 27 W |
| Standby Power | 0.3 W |
| Standby power for non-maintained/switched maintained emergency devices is measured when the light is off and the charger is in standby mode. For maintained emergency devices, standby power is measured when the light is on and the charger is in standby mode. Typically, charging occurs for the first 16 hours after the device is powered or after a battery discharge. | |
Lamp
| Colour Rendering Index (CRI) | |
|---|---|
| EV-QUADRO-ADV EV-QUADRO-ADV-S EV-QUADRO-EM-ADV EV-QUADRO-EM-ADV-S | >80 |
| EV-QUADRO-EM-PRO EV-QUADRO-EM-PRO-LK EV-QUADRO-EM-PRO-S EV-QUADRO-EM-PRO-S-LK EV-QUADRO-PRO EV-QUADRO-PRO-LK EV-QUADRO-PRO-S EV-QUADRO-PRO-S-LK | >84 |
| CCT Configuration | |
| EV-QUADRO-ADV EV-QUADRO-ADV-S EV-QUADRO-EM-ADV EV-QUADRO-EM-ADV-S | TRI-CCT |
| EV-QUADRO-EM-PRO EV-QUADRO-EM-PRO-LK EV-QUADRO-EM-PRO-S EV-QUADRO-EM-PRO-S-LK EV-QUADRO-PRO EV-QUADRO-PRO-LK EV-QUADRO-PRO-S EV-QUADRO-PRO-S-LK | TUNEABLE WHITE |
| Full support for DALI-2 DT8 has been provided which allows White colour control on a compliant DALI-2 control system. This function can be used to set a desired colour or to transition between colours depending on the time of day. | |
| Macadam Steps (SDCM) | |
| EV-QUADRO-EM-PRO EV-QUADRO-EM-PRO-LK EV-QUADRO-EM-PRO-S EV-QUADRO-EM-PRO-S-LK EV-QUADRO-PRO EV-QUADRO-PRO-LK EV-QUADRO-PRO-S EV-QUADRO-PRO-S-LK | 3 SDCM |
| EV-QUADRO-ADV EV-QUADRO-ADV-S EV-QUADRO-EM-ADV EV-QUADRO-EM-ADV-S | 5 SDCM |
| Lamp/LED voltage | 36 V |
| Lamp/LED Current | |
| EV-QUADRO-ADV EV-QUADRO-ADV-S EV-QUADRO-EM-ADV EV-QUADRO-EM-ADV-S | 460 mA |
| EV-QUADRO-EM-PRO EV-QUADRO-EM-PRO-LK EV-QUADRO-EM-PRO-S EV-QUADRO-EM-PRO-S-LK EV-QUADRO-PRO EV-QUADRO-PRO-LK EV-QUADRO-PRO-S EV-QUADRO-PRO-S-LK | 650 mA |
LED Lifetime
| LED Lifetime | >120000 hrs | ||||||
|---|---|---|---|---|---|---|---|
| This is the Reported LED Lifetime in Hours based on TM-21. Ektor does not list the projected or calculated LED lifetime, which is normally longer as TM-21 Addendum B explicitly states "The Calculated and Projected Lp(Dk) are not to be reported". This Lifetime refers to the life of a single LED however the system life is longer since the probability and binomial distribution of all LEDs in the system means that the average led is performing above the specification and compensates for the LEDs falling below. | |||||||
| LED Lifetime Ratings (Failure rate & lumen depreciation) | |||||||
EV-QUADRO-ADV |
| ||||||
EV-QUADRO-ADV-S |
| ||||||
EV-QUADRO-EM-ADV |
| ||||||
EV-QUADRO-EM-ADV-S |
| ||||||
EV-QUADRO-EM-PRO EV-QUADRO-EM-PRO-LK EV-QUADRO-EM-PRO-S EV-QUADRO-EM-PRO-S-LK EV-QUADRO-PRO EV-QUADRO-PRO-LK EV-QUADRO-PRO-S EV-QUADRO-PRO-S-LK |
| ||||||
| This rating defines the performance of the led within its lifetime. L relates to lumen depreciation, where the proceeding number gives the resultant lumen output at the end of it reported lifetime. L70, would mean 30% lumen depreciation which means 70% of its initial output and is tested accordingly to TM-21. The B part refers to failures, which can be define as the percentage of LEDs which fall below the L value in the projected lifetime. A value of B10 refers to 10% failure and a value of B50 refers to 50% failure. After the defined lifetime, the system will reach the defined lumen depreciation and the average led failures is defined by the B rating. The B rating is defined in and tested to IEC62717. | |||||||
| TM-21 Test Hours | |||||||
| EV-QUADRO-ADV EV-QUADRO-ADV-S EV-QUADRO-EM-ADV EV-QUADRO-EM-ADV-S | 9000 hrs | ||||||
| EV-QUADRO-EM-PRO EV-QUADRO-EM-PRO-LK EV-QUADRO-EM-PRO-S EV-QUADRO-EM-PRO-S-LK EV-QUADRO-PRO EV-QUADRO-PRO-LK EV-QUADRO-PRO-S EV-QUADRO-PRO-S-LK | 20000 hrs | ||||||
Colour temperature
| EV-QUADRO-ADV EV-QUADRO-ADV-S EV-QUADRO-EM-ADV EV-QUADRO-EM-ADV-S
| |||||||||||||||||||||
| EV-QUADRO-EM-PRO EV-QUADRO-EM-PRO-LK EV-QUADRO-EM-PRO-S EV-QUADRO-EM-PRO-S-LK EV-QUADRO-PRO EV-QUADRO-PRO-LK EV-QUADRO-PRO-S EV-QUADRO-PRO-S-LK
| |||||||||||||||||||||
Driver
| Driver Type | |
|---|---|
| EV-QUADRO-EM-PRO EV-QUADRO-EM-PRO-S | DALI-DT1-DT8 |
| EV-QUADRO-PRO EV-QUADRO-PRO-S | DALI-DT8 |
| EV-QUADRO-ADV EV-QUADRO-ADV-S EV-QUADRO-EM-ADV EV-QUADRO-EM-ADV-S | Fixed Output |
| EV-QUADRO-EM-PRO-LK EV-QUADRO-EM-PRO-S-LK | WIRELESS-DT1-DT8 |
| EV-QUADRO-PRO-LK EV-QUADRO-PRO-S-LK | WIRELESS-DT8 |
| DALI DT8 ~ Includes DALI-2 Driver with full support for DT6 and DT8-tc allowing flicker free dimming and colour control with compliant DALI-2 Application controllers. Wireless ~ Includes Wireless Driver with full support for DT6 and DT8-tc allowing flicker free dimming and colour control with compliant IEC62386-104 Application controllers. | |
| Driver Included | Yes |
| Integrated Driver | No |
| Dimmable | |
| EV-QUADRO-ADV EV-QUADRO-ADV-S EV-QUADRO-EM-ADV EV-QUADRO-EM-ADV-S | No |
| EV-QUADRO-EM-PRO EV-QUADRO-EM-PRO-LK EV-QUADRO-EM-PRO-S EV-QUADRO-EM-PRO-S-LK EV-QUADRO-PRO EV-QUADRO-PRO-LK EV-QUADRO-PRO-S EV-QUADRO-PRO-S-LK | Yes |
| Wiring Type | |
| EV-QUADRO-ADV EV-QUADRO-ADV-S | Terminal 3 |
| EV-QUADRO-EM-ADV EV-QUADRO-EM-ADV-S | Terminal 4 |
| EV-QUADRO-EM-PRO EV-QUADRO-EM-PRO-LK EV-QUADRO-EM-PRO-S EV-QUADRO-EM-PRO-S-LK EV-QUADRO-PRO EV-QUADRO-PRO-LK EV-QUADRO-PRO-S EV-QUADRO-PRO-S-LK | Terminal 6 |
| Power Monitoring | DALI-DT51 |
| PSTLM | |
| EV-QUADRO-EM-PRO EV-QUADRO-EM-PRO-LK EV-QUADRO-EM-PRO-S EV-QUADRO-EM-PRO-S-LK EV-QUADRO-PRO EV-QUADRO-PRO-LK EV-QUADRO-PRO-S EV-QUADRO-PRO-S-LK | 0.08 |
| EV-QUADRO-ADV EV-QUADRO-ADV-S EV-QUADRO-EM-ADV EV-QUADRO-EM-ADV-S | 0.09 |
| Short Term Light Modulation (PstLM): The requirement is that PstLM should be less than or equal to 1.0. This metric measures the short-term flicker severity and ensures that flicker is not perceptible or is at a level that does not cause discomfort or health issues. | |
| SVM | |
| EV-QUADRO-ADV EV-QUADRO-ADV-S EV-QUADRO-EM-ADV EV-QUADRO-EM-ADV-S | 0.012 |
| EV-QUADRO-EM-PRO EV-QUADRO-EM-PRO-LK EV-QUADRO-EM-PRO-S EV-QUADRO-EM-PRO-S-LK EV-QUADRO-PRO EV-QUADRO-PRO-LK EV-QUADRO-PRO-S EV-QUADRO-PRO-S-LK | 0.018 |
| Stroboscopic Visibility Measure (SVM): The requirement for SVM is that it should be less than or equal to 0.4. The SVM metric assesses the visibility of the stroboscopic effect, which can make moving objects appear to be stationary or moving in discrete steps, thus ensuring that this effect is minimized in lighting environments to prevent visual discomfort and safety hazards. | |
Sensor (S suffix)
| Sensor Type | Microwave |
|---|---|
| Detection Range | 10 m |
| Time Delay | |
| EV-QUADRO-ADV-S EV-QUADRO-EM-ADV-S | 5s-14mins |
| EV-QUADRO-EM-PRO-S EV-QUADRO-EM-PRO-S-LK EV-QUADRO-PRO-S EV-QUADRO-PRO-S-LK | Via DALI |
| Switched Output | No |
| Corridor Function | Yes |
| Lux Adjustment | |
| EV-QUADRO-EM-PRO-S EV-QUADRO-EM-PRO-S-LK EV-QUADRO-PRO-S EV-QUADRO-PRO-S-LK | No |
| EV-QUADRO-ADV-S EV-QUADRO-EM-ADV-S | Yes |
| Dusk Mode | |
| EV-QUADRO-EM-PRO-S EV-QUADRO-EM-PRO-S-LK EV-QUADRO-PRO-S EV-QUADRO-PRO-S-LK | No |
| EV-QUADRO-ADV-S EV-QUADRO-EM-ADV-S | Yes |
| Adjustable Hold Time | Yes |
| Adjustable Standby Level | Yes |
| Adjustable Standby Period | Yes |
| Adjustable Detection Area / Sensitivity | Yes |
| Manual Override | Yes |
| Dawn Reset | No |
| Sensor Communication | DALI2 |
Emergency (EM suffix)
| Replacement Battery Code | 01302 |
|---|---|
| Emergency Mode | Maintained |
| Emergency Classification | C0:D50, C90:D50 |
| Emergency Duration | 90 mins |
| Emergency Lumen Output | 390 lm |
| Emergency Control | |
| EV-QUADRO-EM-PRO EV-QUADRO-EM-PRO-S | DALI-DT1 |
| EV-QUADRO-EM-PRO-LK EV-QUADRO-EM-PRO-S-LK | WIRELESS-DT1 |
Compliance
| Product Design Life | |
|---|---|
| EV-QUADRO-EM-PRO EV-QUADRO-EM-PRO-LK EV-QUADRO-EM-PRO-S EV-QUADRO-EM-PRO-S-LK EV-QUADRO-PRO EV-QUADRO-PRO-LK EV-QUADRO-PRO-S EV-QUADRO-PRO-S-LK | 12 years |
| EV-QUADRO-ADV EV-QUADRO-ADV-S EV-QUADRO-EM-ADV EV-QUADRO-EM-ADV-S | 8 years |
| The product design life relates to the total product life which includes LEDs, drivers and the enclosure. This is different to the LED lifetime which only refers to the economical lifetime of the LEDs at which time the lumen output has dropped below the L Value. The product design life is calculated at the maximum ambient or working temperature of the product and takes into account the Daily Use. | |
| Standards |
|
Warranty
| VIP Warranty | 2Y3Y |
|---|---|
| VIP warranty is available to registered users and is subjected to additional terms and conditions. Register as a VIP today. Our standard warranty is return-to-base. Onsite warranty is only available to users who are registered, for sites located in the defined areas/regions and for purchases that have been registered. | |
| Commercial Use Warranty | |
| EV-QUADRO-ADV EV-QUADRO-ADV-S EV-QUADRO-PRO EV-QUADRO-PRO-LK EV-QUADRO-PRO-S EV-QUADRO-PRO-S-LK | 0Y5Y |
| EV-QUADRO-EM-ADV EV-QUADRO-EM-ADV-S | 0Y5Y6Y |
| EV-QUADRO-EM-PRO EV-QUADRO-EM-PRO-LK EV-QUADRO-EM-PRO-S EV-QUADRO-EM-PRO-S-LK | 0Y5Y8Y |
