Smart Driver Constant Current

$0.00

Smart Driver with Plug – Constant Power 10W Selected

SKU: Acc-Smart Driver Constant Current Category: Tag:

Mechanical

Body MaterialPolycarbonate
IP RatingIP20

Electrical

Electrical RatingClass II
Input Frequency50 Hz
Input voltage230Vac
In Australia the Input voltage is defined as 230Vac -6%/+10%. This effectively means that the voltage range of these products are 216Vac - 253Vac or 240V +6%
Working Temp Range0 to 55 °C

Driver

DimmableYes
Driver Mode
EV-SMART-DRIVER-DA-1100
EV-SMART-DRIVER-DA-750
EV-SMART-DRIVER-DA-800
EV-SMART-DRIVER-DA-950
EV-SMART-DRIVER-DC-10W
EV-SMART-DRIVER-DC-1100
EV-SMART-DRIVER-DC-750
EV-SMART-DRIVER-DC-800
EV-SMART-DRIVER-DC-950
EV-SMART-DRIVER-DW-1100
EV-SMART-DRIVER-DW-750
EV-SMART-DRIVER-DW-800
EV-SMART-DRIVER-DW-950
Constant Current
EV-SMART-DRIVER-DA-10W
EV-SMART-DRIVER-DW-10W
Constant Power
Driver TypeDALI Dimmable
PSTLM0.08
SVM0.018
Wiring Type
EV-SMART-DRIVER-DC-10W
EV-SMART-DRIVER-DC-1100
EV-SMART-DRIVER-DC-750
EV-SMART-DRIVER-DC-800
EV-SMART-DRIVER-DC-950
CMS Plug (5 pin)
EV-SMART-DRIVER-DA-10W
EV-SMART-DRIVER-DA-1100
EV-SMART-DRIVER-DA-750
EV-SMART-DRIVER-DA-800
EV-SMART-DRIVER-DA-950
Re-wireable terminal block (5 pin)
EV-SMART-DRIVER-DW-10W
EV-SMART-DRIVER-DW-1100
EV-SMART-DRIVER-DW-750
EV-SMART-DRIVER-DW-800
EV-SMART-DRIVER-DW-950
WBC Plug (5 pin)
WBC ~ Supplied with a Wire by click- 5 pin plug, model number LA1025/5
CMS ~ Supplied with a CMS Electracom- 5 pin plug to suit QF series wiring, model number QFP3AT
Driver Power
EV-SMART-DRIVER-DA-10W
EV-SMART-DRIVER-DC-10W
EV-SMART-DRIVER-DW-10W
10 W
EV-SMART-DRIVER-DA-1100
EV-SMART-DRIVER-DA-750
EV-SMART-DRIVER-DA-800
EV-SMART-DRIVER-DA-950
40 W
Driver Current
EV-SMART-DRIVER-DA-750
EV-SMART-DRIVER-DC-750
EV-SMART-DRIVER-DW-750
750 mA
EV-SMART-DRIVER-DA-800
EV-SMART-DRIVER-DC-800
EV-SMART-DRIVER-DW-800
800 mA
EV-SMART-DRIVER-DA-950
EV-SMART-DRIVER-DC-950
EV-SMART-DRIVER-DW-950
950 mA
EV-SMART-DRIVER-DA-1100
EV-SMART-DRIVER-DC-1100
EV-SMART-DRIVER-DW-1100
1100 mA
Output Voltage Range12-38 V
Ordering codeItem codeDescriptionAvailability
12829EV-SMART-DRIVER-DA-10W Smart Driver with Plug - Constant Power 10W Selected
12852EV-SMART-DRIVER-DA-1100 Smart Driver with Plug - Constant Current 1100mA Selected
12848EV-SMART-DRIVER-DA-750 Smart Driver with Plug - Constant Current 750mA Selected
12849EV-SMART-DRIVER-DA-800 Smart Driver with Plug - Constant Current 800mA Selected
12851EV-SMART-DRIVER-DA-950 Smart Driver with Plug - Constant Current 950mA Selected
12959EV-SMART-DRIVER-DC-10W Smart Driver with Flex and Junction Box - Constant Power 10W Selected - 2.4m cable & CMS plug
12963EV-SMART-DRIVER-DC-1100 Smart Driver with Plug - Constant Current 1100mA Selected - 2.4m cable & CMS plug
12960EV-SMART-DRIVER-DC-750 Smart Driver with Plug - Constant Current 750mA Selected - 2.4m cable & CMS plug
12961EV-SMART-DRIVER-DC-800 Smart Driver with Plug - Constant Current 800mA Selected - 2.4m cable & CMS plug
12962EV-SMART-DRIVER-DC-950 Smart Driver with Plug - Constant Current 950mA Selected - 2.4m cable & CMS plug
13002EV-SMART-DRIVER-DW-10W Smart Driver with Flex and Junction Box - Constant Power 10W Selected - 2.4m cable & Wire By Click plug
13006EV-SMART-DRIVER-DW-1100 Smart Driver with Plug - Constant Current 1100mA Selected - 2.4m cable & Wire By Click plug
13003EV-SMART-DRIVER-DW-750 Smart Driver with Plug - Constant Current 750mA Selected - 2.4m cable & Wire By Click plug
13004EV-SMART-DRIVER-DW-800 Smart Driver with Plug - Constant Current 800mA Selected - 2.4m cable & Wire By Click plug
13005EV-SMART-DRIVER-DW-950 Smart Driver with Plug - Constant Current 950mA Selected - 2.4m cable & Wire By Click plug

*Auto generated datasheet (beta)
